LU-923M time-delay relay is an intelligent time alarm instrument with excellent performance and stability.

It adopts advanced ARM processor, fast processing speed,simple interface component,high accuracy in captured time,strong reliability and stability.

It has one high accuracy timing clock and 4 groups alarm register which can be combined freely.Rich time alarm outputs and the output position can be self-defined.

It can receive external reset signal event (dry point),or start the timing just press the panel button.



2. Main Technical Parameters



●Accuracy: ±(0.2%F.S.+1)digit

●Resolution: 1℃ , 0.1℃

●Control method:ON/OFF,manual control,PID with auto-tuning

●Display: double 4-bit LED +light pillar

●Output modules:

J5: relay output (250VAC/3A,normally open)

J6: relay output (250VAC/0.8A,normally open)

J8:relay output (250VAC/3A,normally open+normally close)

J9:relay output (250VAC/0.8A,normally open+normally close)

J7:double relay output (250VAC/0.8A,normally open)

G1: SSR trigger output

D1: switch input signal

S2: RS232 communication

S4: RS485 communication

●T.C cold Junction compensation error: ±1℃

●T.C.break or over range: display Sb

●Sampling period: 0.5 second

●Power voltage: 85~265VAC

●Power consumption: <4W
